Blowing machine

The bottle blowing machine is suitable for blowing various shapes of bottles made of PET/RPET/PCR/PLA and other plastics, including carbonated drink bottles, mineral water bottles, pesticide bottles, cosmetic bottles, medical bottles, hot-fill bottles, etc. The fully automatic series bottle blowing machine is the main model produced by our company. It adopts advanced design concepts, excellent manufacturing, and high-quality parts from well-known brands, and is suitable for blowing various shapes of PET bottles.

Technical specifications:

	Item	Unit	Range
Finished Product Specifications	Number of cavities	U	1-9
	Max. bottle volume	ml	600-20000
	Max. bottle neck diameter	mm	45-130
	Max. body diameter	mm	65-270
	Max. body height	mm	240-500
SCompressed Air System	Operating pressure	Bar	0.7
	Low pressure operating air consumption	L/min	1200-1600
	Blowing pressure	Bar	2.0-3.5
	Blowing air consumption	L/min	1600-8000
Cooling Water System	Operating pressure	Bar	0.3-0.5
	Cooling water temperature	℃	8-15℃
	Cooling water flow rate	L/min	30-80
